HC241
105kW / 241.152kWh · AC-Coupled
AC-coupled energy storage cabinet designed for retrofit installations. Add battery storage to existing PV arrays without rewiring.
Rated Power
105kW
Capacity
241.152kWh
Battery Type
LiFePO4
Cooling
Air Cooling
Retrofit Ready.
No Rewiring Needed.
AC-Coupled Design
Connects to existing PV inverter AC output — no DC rewiring needed.
Retrofit Ready
Add battery storage to any existing PV system without modifying the original solar installation or inverter.
CCS Module Design
Standardized cell-to-system modular architecture for rapid deployment and flexible capacity configuration.
Safe & Reliable
LiFePO4 cells with multi-layer protection: thermal warning algorithms, fire suppression, and explosive venting.
Flexible Grid Switching
Seamless on-grid / off-grid transfer switching for uninterrupted power supply during grid outages.
User-Friendly
Intuitive monitoring interface, OTA firmware updates, and remote diagnostics via cloud-based EMS platform.
Technical Specifications
| Rated Power | 105kW |
| Maximum Current | 167A |
| Rated Voltage | 400V |
| Wiring Method | 3P4L+PE |
| Frequency | 50Hz / 60Hz |
| Power Factor | 1 (Leading) ~ 1 (Lagging) |
| THDi | <2% (Rated Power) |
| Rated Power | 105kW |
| Rated Voltage | 400V |
| Maximum Current | 167A |
| Wiring Method | 3P4L+PE |
| Frequency | 50Hz / 60Hz |
| THDu | <3% (Linear Load) |
| Battery Type | LiFePO4 |
| Battery Cell | 3.2V / 314Ah |
| Battery Pack Configuration | 1P16S |
| Battery Pack Quantity | 15 Packs / Cluster |
| Rated Current | 157A |
| Voltage Range | 648 – 864V |
| Rated Capacity | 241.152kWh |
| Weight | 2.5T |
| Dimensions (W×D×H) | 1600×1103×2254mm |
| Maximum Efficiency | ≥85% |
| Air Conditioning Power | 3kW (Cooling), 2.5kW (Heating) |
| Temperature | -20°C ~ 50°C (De-Rating Over 45°C) |
| Humidity | 5% ~ 95%RH (Non-Condensation) |
| Protection Level | IP54 |
| Anti-corrosion Rating | C4 |
| Cooling Method | Air Cooling |
| Noise | ≤75dB |
| Altitude | 2000m (>2000m Derating) |
| Display | LCD |
| Fire Protection | FK-5-1-12 |
| Communication | Ethernet |
| Certification | CE, UN38.3 |
| Charge/Discharge Rate | 0.5CP |
| Depth of Discharge | 90% |
| Cycle Life | ≥6000 Cycles (80% SOH @ Standard) |
Built for Retrofit
Energy Storage.
Industrial Peak Shaving
Reduce peak demand charges by 30–50% through intelligent charge/discharge scheduling aligned with tariff periods.
PV Retrofit Storage
Add battery storage to existing PV installations without DC rewiring — maximize ROI on legacy solar arrays.
Backup Power
Seamless off-grid switching ensures uninterrupted power for critical loads during grid outages.
